Fruit and vegetable respiration meter
I. Instrument Application
Harvested fruits and vegetables remain independent living organisms, and respiration is essential for their survival. Respiration is the primary physiological metabolic process for horticultural products such as fruits and vegetables after harvesting. Respiration intensity is an indicator of the strength of respiration and is a crucial indicator for studying the physiological changes of fruits and vegetables after harvesting and for storage, transportation, and preservation.
This fruit and vegetable respiration analyzer uses a dual-wavelength infrared carbon dioxide analyzer and a 7-inch Android display. It is specifically designed for measuring and analyzing the respiration intensity of fruits and vegetables under storage conditions such as ambient temperature, cold storage, controlled atmosphere storage, and supermarket freezers.
The instrument's features include the ability to select respiration chambers of different volumes according to the size of the fruits and vegetables, accelerating equilibration and measurement time; and direct display of CO2 concentration, O2 concentration, temperature, and humidity within the respiration chamber, along with their variation curves.
II. Instrument Features:
1. Android operating system for more convenient human-computer interaction.
2. 7-inch high-definition touchscreen, simple operation and clear interface.
3. Gas flow rate can be directly set through the instrument, allowing for experiments on the respiration intensity of fruits and vegetables at different flow rates.
4. Dedicated dynamic analysis software allows real-time display of the experimental process on the Android screen, eliminating the need to copy data to a computer for processing and analysis.
5. Input of elements such as the type, name, weight, origin, and harvest date of the tested fruits or vegetables.
6. 16GB storage space, capable of storing over 100,000 data entries.
7. Data can be directly exported to a USB flash drive via the USB interface.
III. Technical Specifications
1. Carbon Dioxide
Detection Principle: Non-dispersive infrared method
Sensitivity: Carbon dioxide difference acquisition can be completed within 1 second.
Measurement Range: 0-5000ppm
Accuracy: 3ppm
Resolution: 0.1ppm
2. Oxygen Detection
Detection Principle: Electrochemical
Measurement Range: 0-100%
Linearity: ≤±2%F.S
Repeatability: ≤±1%
Response Time: 30s
Zero Drift: ≤±2%F.S/24h
Endpoint Drift: ≤±2%F.S/24h
3. Temperature Detection
Measurement Range: -20-95℃
Resolution: 0.1℃
Accuracy: ±0.2℃
4. Humidity Detection
Measurement Range: 0-100%
Resolution: 0.1%
Accuracy: ±0.2%F.S
5. Power Supply: 12V 3A power adapter
IV. Breathing Chamber Parameters
1. Net space of 80mm with an inner diameter of 40mm 1. **Volume:** 0.1 liters
2. **Clear space:** 89 mm (inner diameter 60 mm), volume 0.25 liters
3. **Clear space:** 180 mm (inner diameter 120 mm), volume 2 liters
V. Accessories
Name | Quantity | Unit
Main Unit | 1 unit
Breathing Chamber | 3 sets
Power Cord | 1 piece
Tracheal Tubes | 2 pieces
Instruction Manual | 1 copy
USB Flash Drive | 1 piece
Instrument Case | 1 piece
Packing List | 1 copy
Instruction Manual | 1 copy
Certificate of Conformity | 1 copy
